6Hi Leveler Trapezoidal Sheet Blanking Line SUS Stainless Steel 0.3 - 3 X 1650

Rotary Shear Fly cut to length line, made by our company, is high speed high precision, esp. suitable for thin sheet short sheet metal cutting:

• Fly cutting is suitable for thin Sheet coil long length (thousands of meters) cutting.
• Fly cutting frequency can be up to 150times/min. Line speed 80 -100m/min
• Short sheets cutting means high frequency continuous cutting high productivity.
• High precision 6High leveler, film laminator, dual stackers are high production arrangement.
• The fly cutting line for 0.3 -3.0mm x 1000mmW x 200 -3000mmL.
• The leveling rollers adjusting is automatic by servo pressing backup rollers.

Besides fly shear cut to length lines, we also design and make swaying shear cut to length line to make trapezoidal sheets, more exactly is kind of blanking line.

Parameters:

Composition:

Characters:

1. The line is to make certain inclined degree of trapezoidal steel plates by leveling and swaying shear, composed of uncoiler, leveler, swaying shear, stacker, etc with auxiliary functions of coil loading, length measuring, film coating, sheets delivering and output,etc.
2. The working process is uncoiling, 21roller 6hi leveling, length measuring, sway shear cutting, the cut sheets go to the first stacker until number of stacking reaches preset number, then transfer to second stacker. While the sheets are going to second stacker, output the sheets on first lifting table by roll table and then first stacker return to work state. This way, one steel coil cutting can be continuously going on.
3. The working process is automatic, adopting PLC servo control and HMI. On touch screen, can set sheet sizes, number of pcs, calculate sheets weight, moreover, has functions: set feeding speed,set feeding length, set number of feeding, interchange between manual and auto, auto start, auto stop, pause, counter zero, fwd-rwd button, shear up-down, faults alarm, etc.
4. The chrome coated rollers, PU rollers, blower, etc play role in protecting sheet surface from being hurt.
5. Except for manual threading, all in auto working.

We are metal coil sheet processing machine manufacturer and supplier, we dedicate to supply of good quality machines and provision of complete services.

We work in the coil processing machine field for over 20years, we design and make each machine customized. From machine parts materials selection, each part machining and treatment, whole machine assembly and surface painting, we carefully note each detail of whole production process to achieve good quality machine result.

Rich Experiences:

Our people witness the developing process of sheet processing machines and develop ourselves with market, thus able to supply customers good machines at competitive prices.

Efficient Responses:

Investment of metallurgical equipment is a system engineering, which requires comprehensive plan and successive execution. The efficient responses of the equipment suppliers are very important. We did well in this and cooperate with customers for long time.

Senses of Mission:

Nothing proceeds smoothly without any problem, the important is to face and solve the problem. We put problem solution in priority, never escape responsibilities. Supply of good machines creating profit for customers is our mission, the most profitable equipment is the best. Customer is the King, we must provide him the most suitable machine to return his trust.

After-sale Services:

We can send engineers to customer plant to do machine installation and commissioning; we provide hydraulic schematic drawing, electric principle diagrams, mechanic spare parts drawings, civil works drawing; We always listen and give consultation.

Welcome to inquire us! welcome to visit our plants!
